Glenair熱電偶/氣動/PC尾部等特殊用途接觸件
發布時間:2024-11-18 08:53:05 瀏覽:1622

Glenair提供多種特殊用途的高性能接觸件,包括熱電偶、氣動、PC尾部、高功率、焊杯等接觸件。
| Glenair Part | Part Description | Contact | Type | Product |
| Number | Size | Page | ||
| 859-012 | Grommet Sealing Plugs(MS27488 Type) | 0-23 | Sealing Plug | D-3 |
| 809-001 | Series 80 Mighty MousePin Contact | 23 | Crimp Contact | D-4 |
| 809-002 | Series 80 MightyMouseSocket Contact | 23 | Crimp Contact | D-5 |
| 830-004 | Pneumatic Socket Contactfor Series 79,Series 80 and | 12 | Pneumatic | D-6 |
| D38999 Series ll | ||||
| 830-005 | Pneumatic Socket Contact for Series 79,Series 80 and | 12 | Pneumatic | D-6 |
| D38999 Series I,IⅢ,IV | ||||
| 830-003 | Pneumatic Pin Contactfor Series 79,Series 80 and D38999 | 12 | Pneumatic | D-7 |
| Seriesl,II,Ⅲ,IV | ||||
| 850-010 | PCB Pin Contact to ft D38999/20and/24 | 12-22 | PCB Pin | D-8 |
| 850-011 | PCB Socket Contact to fit D38999/20 and/24 | 12-22 | PCB Socket | D-9 |
| 850-013 | HighPower SocketContact | 8 | Power Socket | D-10 |
| 850-014 | High Power Pin Contact | 8 | Power Pin | D-11 |
| 850-015 | M39029/56 Type Socket Contact with Solder Cup | 10-22 | Solder Cup | D-12 |
| 850-016 | Pin Contactwith Solder Cup | 10-22 | SolderCup | D-14 |
| 850-017 | M39029/58 Type Pin Contact with Solder Cup | 12-22 | Solder Cup | D-16 |
| 850-018 | M39029/56-348 Type Socket Contact | 22 | Crimp Contact | D-18 |
| 850-019 | M39029/58-360 Type PinContact | 22 | Crimp Contact | D-19 |
| 850-020 | M39029/57 Type Socket Contact | 22 | Crimp Contact | D-20 |
| 857-027 | M39029/58 Type High Power Pin with PCTails | 8 | PCB Power | D-21 |
| 857-028 | M39029/56 Type High Power Socketwith PCTails | 8 | PCB Power | D-22 |
| 687-348 | Wire to Contact Crimp Adapter | 4-22 | Crimp Adapter | D-23 |
| 850-023 | M39029/87Thermocouple Pin Contact | 16-22 | Thermocouple | D-24 |
| 850-024 | M39029/88 Thermocouple Socket Contact;Series l,I,IV | 16-22 | Thermocouple | D-26 |
| 850-025 | M39029/89 Thermocouple Socket Contact;Series Ⅱ | 16-22 | Thermocouple | D-28 |
選型:
產品特點:
適用于高功率和高電流容量的接觸件。
提供板端接觸件和用于溫度測量的熱電偶接觸件。
還提供各種小型配件,如密封塞等。
解決方案:Glenair 致力于為各種互連挑戰提供專用且獨特的接觸件解決方案。
優勢:
符合 SAE-AS39029 規范的合格和商業接觸件。
熱銷及難找型號的庫存保證當天發貨。
提供優質耐用的材料和電鍍層。
獨特和難找的接觸件類型。
